See Product for In-Stock Quantity - You Can Also Verify Stock By Calling (480) 899-9897 or Texting (480) 226-4551

  • Honeywell M7285C1009 Modutrol IV 120V Foot Mounted Prop SR Low Voltage Actuator [New]

    • Honeywell M7285C1009 Modutrol IV 120V Foot Mounted Prop SR Low Voltage Actuator [New]

    Honeywell

    $1,761.68
    Write a Review
    SKU:
    IT-Y1JG-666U
    UPC:
    783942903768
    Condition:
    New
    Availability:
    In Stock - Ships Immediately
    Shipping:
    Calculated at Checkout
    Adding to cart… category.add_cart_announcement

    Product Description

    Power: 120V 50/60Hz, 34VA, 60 Lb-In. Motor: 4-20 mA or 2-10 Vdc Control, Torque: 60 lb-in. Spring Return. Shaft: Dual-ended shaft, Normally Closed Spring Return. Switches: 2 Auxiliary Switches, Adjustable Stroke, Normally Closed. Replaces MT745T1001-Sprint Ret. Honeywell M7285C1009 Modutrol IV 120V Foot Mounted Proportional SR Low Voltage Actuator, 60 lb-in. NC Spring Return

    90 deg Stroke, 30 Sec, 4-20mA Input, Two Aux Switches. The Series 71, 72 and 76 Modutrol IV Motors are spring return and non-spring return motors used to control dampers and valves. The motors accept a current or voltage signal from an electronic controller to position a damper or valve at any point between open and closed. FEATURES: Replaces M734H,J,; M744S,T,Y; and M745L,S,T,Y Motors. M7164, M7261, M7284, and M7294 are non-spring return motors; M7282, M7285, M7286 and M7685 are spring return motors. Integral spring return returns motor to normal position when power is interrupted. Integral junction box provides NEMA 3 weather protection. Motor and circuitry operate from 24 Vac. Models available with factory installed transformer, or a field added internal transformer. Quick-connect terminals are standard”screw terminal adapter is available. Adapter bracket for matching shaft height of older motors is available. Most motors have field adjustable stroke (90° to 160°). Die-cast aluminum housing. Integral auxiliary switches are available factory mounted, or can be field added. Nominal timing standard of 30 seconds (90° stroke), and 60 seconds (160° stroke). Other timings available. Spring return motors can operate valve linkages from power end or auxiliary end shafts for normally closed or normally open valve applications. All models have dual shafts (slotted and tapped on both ends). All models have auxiliary switch cams. Fixed torque throughout the entire voltage range. Motors are designed for either normally open or normally closed valves and dampers. Models available with adjustable start (zero) and span. Models available with 4 to 20 mA input signal. Models available with 2 to 10 Vdc input signal.. Honeywell. Honeywell. M7285C1009.

    Other Details

    B2E Surplus offers a 90-day warranty on all sales. Warranted to be free from defects in materials and workmanship under normal use and service. Unless otherwise set forth in a quotation or agreed to by B2E Surplus in writing, standard Products are warranted for 90 days from the date of delivery to the buyer. Subject to the exclusions described below, all B2E Surplus products (“Products”) are warranted to be free from defects in materials and workmanship under normal use and service. Unless otherwise set forth in a quotation or agreed to by B2E Surplus in writing, standard Products are warranted for 90 days from the date of delivery to the buyer. EXCLUSIVE REMEDY. In the event that B2E Surplus determines that a Product contains a defect in materials or workmanship, then B2E Surplus, in its sole discretion, will (a) repair the Product, (b) replace the Product, or (c) refund the purchase price of the Product. THIS LIMITED WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE REMEDY OF REPAIR, REPLACEMENT OR REFUND IS BUYER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY. IN NO EVENT SHALL B2E SURPLUS’ LIABILITY UNDER THIS WARRANTY EXCEED THE PURCHASE PRICE OF THE PRODUCT GIVING RISE TO THE WARRANTY CLAIM. All Products which are repaired or replaced shall be warranted only for the unexpired portion of the original warranty period. EXCLUSIONS. This warranty does not cover (a) any failures which are not attributable to defects in materials or workmanship, including without limitation, failures caused by accidents, inadequate maintenance, misuse, unauthorized modifications or repairs, improper storage, and normal wear and tear, (b) any consumable parts or accessories, such as cutter blades, nut splitter chisels, punches, dies, chains, wedges, and strands, that are designed to wear over time or through use of the Product, or (c) electronics, motors, batteries, and engines, as these items are warranted by their manufacturer. WARRANTY RETURNS. No Products shall be returned without prior authorization from B2E Surplus. Buyer shall prepay all shipping charges for the return of Products to B2E Surplus’ designated service location. LIMITATION OF LIABILITY. IN NO EVENT SHALL B2E SURPLUS BE LIABLE FOR ANY INCIDENTAL DAMAGES, CONSEQUENTIAL DAMAGES, SPECIAL DAMAGES, INDIRECT DAMAGES, LOSS OF PROFITS, LOSS OF REVENUES, OR LOSS OF USE, EVEN IF INFORMED OF THE POSSIBILITY OF SUCH DAMAGES. B2E SURPLUS' LIABILITY FOR DAMAGES ARISING OUT OF OR RELATED TO ANY ORDER IS LIMITED TO THE ORDER PRICE FOR THE SPECIFIC PRODUCT THAT GIVES RISE TO THE CLAIM. TO THE EXTENT PERMITTED BY APPLICABLE LAW, THESE LIMITATIONS AND EXCLUSIONS SHALL APPLY REGARDLESS OF WHETHER LIABILITY ARISES FROM BREACH OF CONTRACT, WARRANTY, TORT (INCLUDING BUT NOT LIMITED TO NEGLIGENCE), BY OPERATION OR LAW, OR OTHERWISE.
