Name: Parker Veriflo 930AOPLPNCSE1111 54015197 Quantum 930 Series Diaphragm Valve [New]
Brand: Veriflo
SKU: Y3-2KW7-DOHY
Price: 834.48 USD
Availability: InStock

Overview
Other Details

Product Description

Series: Quantum 930. Type (AOPLPNC): Air Operated, Low Pressure, Normally Closed. Material (S): 316 VAR Stainless Steel. Part # Suffix (E1111): E1111. Known Alias OEM Part #(s): 101-32025-000. The 930 Series valves are designed for ultra high purity applications for Semiconductor OEM and process wafer manufacturing. The 930 Series is available with a variety of manual operators and air operated actuators. The air operated actuators are provided with an LP (125 PSI) or an MP (300 PSI) operating range. The 300 psig operating pressure for both the manual and the AOPMP (mid-pressure) valves offers an extended application range for this product series. Standard surface finish 5 micro inch Ra. Internally threadless and springless. Fully functional from vacuum to 300 psig. High cycle life (including corrosive service). 100% Helium leak tested. Standard full internal electroplish. Minimal particle generation and particle entrapment areas. Vericleanâ€žÂ¢, Veriflo's low sulfur high purity 316L Stainless Steel enhances electropolishing, welding, and corrosion resistance. BODY MATERIAL VeriClean 316L Stainless Steel; DIAPHRAGM MATERIAL Elgiloy, equivalent; SEAT MATERIAL PCTFE (std), PEEK, Vespel; CAP MATERIAL 17-4 Stainless Steel; NUT MATERIAL 316L Stainless Steel; HOUSING MATERIAL Anodized Aluminum; PROOF PRESSURE 188 psig (13 barg); BURST PRESSURE 375 psig (26 barg); FLOW CAPACITY (CV) Cv 0.3; INTERNAL LEAK RATE ? 1 x 10Â¯9 scc/sec He; EXTERNAL LEAK RATE ? 2 x 10Â¯10 scc/sec He; INTERNAL VOLUME (CC) 2.64 cc; WEIGHT (LBS) 1.75; WEIGHT (KG) 0.8; SWITCH TYPE Single Pole, Single Throw (SPST), Momentary Action, Non-Adjustable; LEAD LENGTH (INCH) 7 inch lead; WIRING 26 AWG, UL Style 1061, equal twisted pair; WIRE CONNECTION 1/8" strip tinned ends; MAXIMUM INLET PRESSURE (PSIG) 125 psig; MAXIMUM INLET PRESSURE (BARG) 8.6 barg; ACTUATION PRESSURE 75 psig nominal (5 barg); BAKE OUT TEMPERATURE (C) 121Â°C in the open position; BAKE OUT TEMPERATURE (F) 250Â°F in the open position; MAXIMUM WORKING TEMPERATURE (C) 66Â°C; MAXIMUM WORKING TEMPERATURE (F) 150Â°F; MINIMUM WORKING TEMPERATURE (C) -40Â°C; MINIMUM WORKING TEMPERATURE (F) -40Â°F. Veriflo. Parker. 54015197.

Other Details

B2E Surplus offers a 90-day warranty on all sales. Warranted to be free from defects in materials and workmanship under normal use and service. Unless otherwise set forth in a quotation or agreed to by B2E Surplus in writing, standard Products are warranted for 90 days from the date of delivery to the buyer. Subject to the exclusions described below, all B2E Surplus products (Products) are warranted to be free from defects in materials and workmanship under normal use and service. Unless otherwise set forth in a quotation or agreed to by B2E Surplus in writing, standard Products are warranted for 90 days from the date of delivery to the buyer. EXCLUSIVE REMEDY. In the event that B2E Surplus determines that a Product contains a defect in materials or workmanship, then B2E Surplus, in its sole discretion, will (a) repair the Product, (b) replace the Product, or (c) refund the purchase price of the Product. THIS LIMITED WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE REMEDY OF REPAIR, REPLACEMENT OR REFUND IS BUYERS SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY. IN NO EVENT SHALL B2E SURPLUS LIABILITY UNDER THIS WARRANTY EXCEED THE PURCHASE PRICE OF THE PRODUCT GIVING RISE TO THE WARRANTY CLAIM. All Products which are repaired or replaced shall be warranted only for the unexpired portion of the original warranty period. EXCLUSIONS. This warranty does not cover (a) any failures which are not attributable to defects in materials or workmanship, including without limitation, failures caused by accidents, inadequate maintenance, misuse, unauthorized modifications or repairs, improper storage, and normal wear and tear, (b) any consumable parts or accessories, such as cutter blades, nut splitter chisels, punches, dies, chains, wedges, and strands, that are designed to wear over time or through use of the Product, or (c) electronics, motors, batteries, and engines, as these items are warranted by their manufacturer. WARRANTY RETURNS. No Products shall be returned without prior authorization from B2E Surplus. Buyer shall prepay all shipping charges for the return of Products to B2E Surplus designated service location. LIMITATION OF LIABILITY. IN NO EVENT SHALL B2E SURPLUS BE LIABLE FOR ANY INCIDENTAL DAMAGES, CONSEQUENTIAL DAMAGES, SPECIAL DAMAGES, INDIRECT DAMAGES, LOSS OF PROFITS, LOSS OF REVENUES, OR LOSS OF USE, EVEN IF INFORMED OF THE POSSIBILITY OF SUCH DAMAGES. B2E SURPLUS' LIABILITY FOR DAMAGES ARISING OUT OF OR RELATED TO ANY ORDER IS LIMITED TO THE ORDER PRICE FOR THE SPECIFIC PRODUCT THAT GIVES RISE TO THE CLAIM. TO THE EXTENT PERMITTED BY APPLICABLE LAW, THESE LIMITATIONS AND EXCLUSIONS SHALL APPLY REGARDLESS OF WHETHER LIABILITY ARISES FROM BREACH OF CONTRACT, WARRANTY, TORT (INCLUDING BUT NOT LIMITED TO NEGLIGENCE), BY OPERATION OR LAW, OR OTHERWISE.
