Name: Phoenix Contact 2700200 Unmanaged Industrial Ethernet Switch 1600, 5 M12 Ports [New]
Brand: Phoenix Contact
SKU: B2E-TRO-36657
Price: 417.24 USD
Availability: InStock

Overview
Other Details

Product Description

. . . . . Phoenix Contact 2700200 Unmanaged Industrial Ethernet Switch 1600, 5 M12 ports 10/100 Mbps, degree of protection: IP65/IP66/IP67, PROFINET Conformance-Class A

Ethernet interface: The FL SWITCH 1605 M12 has five Ethernet ports on the front in M12 format, to which only CAT5/CAT6 Ethernet cables with D-coded M12 connectors can be connected. The data transmission speed is 10 Mbps or 100 Mbps. In addition, each port has an autocrossing function at 100 Mbps. It is not necessary to distinguish between 1:1 and crossover Ethernet cables. Switching properties of the FL SWITCH 1605 M12 - Store and forward: The switch independently learns the addresses for terminal devices, which are connected via a port, by evaluating the source addresses in the data telegrams. Only packets with unknown addresses, with a source address of this port or with a multicast/broadcast address in the destination address field are forwarded via the corresponding port. The switch can store up to 4096 addresses in its address table with an aging time of 40 seconds. This is important if more than one terminal device is connected to one or more ports. In this way, several independent subnets can be connected to one switch. - Multi-address function: The switch independently learns the addresses for terminal devices, which are connected via a port, by evaluating the source addresses in the data telegrams. Only packets with unknown addresses, with a source address of this port or with a multicast/broadcast address in the destination address field are forwarded via the corresponding port. The switch can store up to 4096 addresses in its address table with an aging time of 40 seconds. This is important if more than one terminal device is connected to one or more ports. In this way, several independent subnets can be connected to one switch. - Quality of Service (QoS) With the aid of the Quality of Service function, the switch can process PROFINET traffic preferentially. To do this, the switch detects the QoS priority from the Ethernet packets and forwards the Ethernet packets with higher priority first.. Phoenix Contact. Phoenix Contact. 2700200.
